TU 651 LRF-A - Thermal Riflescope
-
640×512 12 μm Sensor Resolution
-
2800 yd Detection Range
-
50mm; F1.0 Focal length
-
1440x1080 Display Resolution
-
Integrated Laser Range Finder
- Ballistic Calculator
CORE CHARACTERISTICS
| Sensor |
| Type |
Uncooled VOx Infrared Detector, 8 to 14μm |
| Resolution |
640×512@12μm |
| NETD |
20mK |
| Frame rate |
50 Hz |
| Lens |
| Objective lens |
50mm, F1.0 |
| Field of view |
8.8°×7.0° |
| FOV m@100m |
15×12 |
| Magnification |
3.0x~23.6x |
| Detection range |
2600m/2800yd |
| Display |
| Display type |
0.49'' AMOLED 1440×1080 |
| Color palettes |
White Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia |
| Eyepiece |
Eye relief: 48 mm; Diopter ± 4; Zoom: 14x |
| Hardware |
| Laser rangefinder |
1500m/1630yd |
| WIFI |
2.4G |
| Interface |
USB Type-C; Micro HDMI |
| Tube diameter |
Standard 30 mm |
| Others |
Microphone, Bluetooth |
| System |
| Recording function |
Photo/Video (Audio recording included) |
| Memory capacity |
128GB |
| Power |
| Battery type |
Single 18650 battery (built-in) and customized battery (external) |
| Operating time |
12 hours |
| Environmental |
| Operating temp. |
-30°C to 50°C / -22°F to +122°F |
| Shock |
800G at 1ms half sine pulse (as per IEC60068-2-27) |
| Encapsulation |
IP67 |
| Physical |
| Weight (g/oz) |
1171/41.31 |
| Size (mm/in) |
381×106×99/15.00×4.17×3.90 |
